Automatic PP / PE / PC Hollow Board Production Line For Plastic Grid Machine

Automatic PP / PE / PC Hollow Board Production Line For Plastic Grid Machine

    • Automatic PP / PE / PC Hollow  Board Production Line For Plastic Grid Machine
    • Automatic PP / PE / PC Hollow  Board Production Line For Plastic Grid Machine
  • Automatic PP / PE / PC Hollow  Board Production Line For Plastic Grid Machine

    Product Details:

    Place of Origin: China
    Brand Name: AORUI
    Certification: CE UL CSA
    Model Number: Sj90/33 SJ120/33

    Payment & Shipping Terms:

    Minimum Order Quantity: One set
    Price: Negotiable
    Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
    Delivery Time: 30 days
    Payment Terms: T/T L/C
    Supply Ability: 10 Sets per month
    Contact Now
    Detailed Product Description



    Automatic PP / PE / PC Hollow Board Production Line For Plastic Grid Machine







    Quick detail :



       Material : pp pe pc pvc

       Screw design : single screw

       Screw number:SJ90/33 SJ120/33

        Product: pp pe pc hollow board

       Board width: 1220-2100mm

       Board thickness:2-16mm





    Description:



    This production line realizes continuous production of PC/PE/PP hollow grid plate, which is applicable to

    construction decoration, advertisement collocation, and noise insulation of highway as well as packaging.

    PE/PP hollow grid plate is an ideal substitute of paper box in making packaging box. It is characterized by

    light weight, high intensity, dampproof, , waterproof, and anticorrosion. The width of the products is

    1220-2100mm, and the thickness is 2mm-12mm.



    1.Extruder: The specially designed screw and the advanced controlling system ensure excellent

    plasticization, high output and stable extruding.



    2.Screen changer: Quick screen changer of hydraulic system ensures the short course of screen

    changing.



    3.Mould: Mould adopts high-quality alloy steel and throtting device to guarantee even thickness of the

    plate.



    4.Vacuum calibrating table: Heating exchanging and cooling system of quick speed in calibrating system

    alternate effectively and ordinally with vacuum system, which ensures calibrating precision.



    5.Tractor: There are two tractors. The first one is of high power, high reduction ratio, multi-roller type, well

    low-speed operation, and in addition it is equipped with edge-cutting device to ensure the valid width and

    smooth cut of the edges.



    6.Stress remover: The advanced large area conductive heating mode can effectively remove the stress of

    plate and further improve planeness of the plate.



    7.Cutting machine: Accurate instant length-fixed cutting and automatic up-down discharging system

    combined with alloy steel sharp blade realize high quality of cutting.





    Applications:



    1) Telephone booths


    2) Road signs and advertisements


    3) Billboards on lamp boxes


    4) Lighting and partition walls for banks, hospitals and stations


    5) Greenhouses for vegetables, zoos, aquatic products


    6) Sound and heat insulation for expressways


    7) Instrument and war industries - windscreens, army shields



    Automatic PP / PE / PC Hollow  Board Production Line For Plastic Grid MachineAutomatic PP / PE / PC Hollow  Board Production Line For Plastic Grid Machine





    Specifications:



    Item

    Quantity

    Automatic dry feeding system

    one set

    120/35 Vented single screw extruder

    one set

    45/30 Co-extrusion extruder

    one set

    Hydraulic screen exchanger(for 120 extruder)

    one set

    Metering pump(for 120 extruder)

    one set

    Divider

    one set

    T-die molds

    one set

    Vacuum Calibration unit

    one set

    The first haul-off unit and Side trimming machine

    one set

    Anneal oven

    one set

    Second haul-off unit

    one set

    Protective film covering unit

    one set

    Transverse cutter

    one set

    Transmission equipment

    one set

    Electrical control system

    one set

    Spare parts list

    one set

    Datum along with equipment

    One set







    Competitive Advantage:



    1.high output, low maintenance
    2.imported electric device,Siemens

    3.good after service
