SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry

SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry

    • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry
    • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry
    • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry
    • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry
    • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry
  • SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry

    Product Details:

    Place of Origin: Tianjin China
    Brand Name: XQS
    Certification: ISO9001,BV,SGS,CE,UL6
    Model Number: G.I. Coils 8

    Payment & Shipping Terms:

    Minimum Order Quantity: 20Ton/Tons/MT or according customers’ requirements
    Price: Negotiable
    Packaging Details: Wrapped by Plastic Film and Waterproof Paper and then Fasten on Wooden Pallet
    Delivery Time: 15-20 days after receiving 30%T/T Deposit or L/C At Sight.
    Payment Terms: T/T, L/C At Sight, Western Union,D/A,D/P, Money Gram
    Supply Ability: 400,000 Ton per year
    Contact Now
    Detailed Product Description



    SGCD DX53D+Z Hot Dip Galvanised Steel Tubing Coils JIS G3313 For Commercial Industry





    Quick Detail:



    Thickness

    /mm

    0.25-5.0

    Zinc Coated

    /(g/m2)

    50-350

    Coil Weight

    /kg

    25-1000

    Width/mm

    15mm-300mm ,900mm-1500mm or according customers’ requirements

    Technique

    Hot Rolled

    Spangle

    regular, min , zero and big

    Standard

    JIS G3302/94, JIS G3313, ASTM A653, EN 10142, DX 51D,GB/T 2518-88,

    ISO 6316:2000, ASTM A53, BS1387-1985, GB/T3091-93-2008 etc

    Steel Grade

    Q195-Q235, Q195, Q215, Q235, Q345, SS400, ST37-2, STK400, STK500, 16Mn,

    SGCC,SPCC,DX51D, SGCC/DX51D+Z, DX52D+Z,

    SGCD/DX53D+Z, DX56D+Z, SGCC(DX51D+Z),SGCC(DX53D+Z),SGCE(DX54D+Z) ,

    S350GD ,DX53D+Z, DX54D+Z etc





    Specifications :



    We are the manufacturer of steel pipe/tube and steel coils. Supply high quality various sizes products,

    the cheapest price and the best service for you. The list size we often produce for your reference.

    We also always have the huge ready stock for sell.



    Commodity

    SGCD DX53D+Z Hot Dipped Galvanised Steel Coils / HDGI Coils JIS G3302/94  JIS G3313 For Commercial Industry

    Thickness

    0.25-5.0mm

    Width

    15mm-300mm ,900mm-1500mm or according customers’ requirements

    Zinc Coated

    50g/m2-350g/m2 or according customers’ requirements

    Tolerance Width

    +0.1mm/-0.1mm

    Tolerance Thickness

    +0.03mm/-0.03mm

    Coil Weight

    25kg-1000kg or According Customers’ requirements

    Tensile Strength

    280Mpa-950Mpa

    Elongation

    15%-20% or >20%

    Inner Diameter

    80mm-610mm or  According Customers’ requirements

    Surface Treatment

    1.Hot Dipped Galvanized, Regular Spangle, Slight Oiled or Non Oiled, Dry

    2.Surface Waxed and Edges Debarred

    Spangle

    regular, min , zero and big

    Price

    Get the Latest Price

    Package

    Inner is protect humidity-proof waw paper, Medium is plastic film,

    Outer is sackcloth or compound paper packing,

    or as per customer's requirements

    Port

    Tianjin Port   Xingang Port

    Lead Time

    15-20 days after receiving 30%T/T Deposit or L/C At Sight.

    Payment Term

    T/T ,L/C At sight ,Western Union,D/A,D/P

    MOQ

    20Ton/Tons

    Supply Ability

    400,000 Ton/Tons/MT per Year

    Application

    Galvanized Steel Coils/Strips/Sheets are used to cut into narrow galvanized

    steel sheets/strips .

    Galvanized steel Coils / Strips / Sheets / GI Steel Coils are generally used to

    make pipes, such as: greenhouse pipes, water pipes, heating pipes, gas pipes;

    also can be used in architecture, light industry,automobile, agriculture and

     animal husbandry and fishery and commercial industries.

    Galvanized steel Coils / Strips / Sheets / GI Steel Coils are mainly used in

     the manufacture of corrosion protection of industrial and civil building roof panel,

     roof grate in the construction industry . In the light industry, Galvanized steel Coils

     / Strips / Sheets / GI Steel Coils are used to manufacture the shell of household

     electrical appliance, civil chimney, kitchen appliances and so on. In the automotive

     industry, Galvanized steel Coils / Strips / Sheets / GI Steel Coils are mainly used

     in the manufacture of anti-corrosive parts of car.

    In agriculture and Animal Husbandry Fishery, they are mainly used as

     freezing processing tools of grain storage, meat and aquatic products.

     In business, the are mainly used as storage and transportation, packaging tools

     of materials.

     At the same time, They can also be used in the manufacture of steel purlin

     (C, Z type steel), light steel keel, ceiling keel.

    Remark

    The materials of these specifications are Q195-Q235,Q195L material and

     Q345B material can be customized according customers’ requirements,

    the price for these customized specifications is negotiable.

    We can supply any custom dimension, specification zinc coated and other

    international standards to fit your needs.

    Help you to control the cost to maximize the profit.

    Hope to cooperate with you in the early future.

    Contact Info.



    Mr. Wang

    International Trade Sales Manager

    Tel: +86-022-68729310

    Your early reply will be highly appreciated





    Competitive Advantage:



    We have our own Steel Strip / Steel Coils’s Open-flat Longitudinal Cutting Processing Line.

    Open-flat Longitudinal Cutting Processing is the process of making steel coils / steel strips

    or steel plate narrower and shorter .

    We can cut the steel coils / steel trips or steel plate into any specification you need.

    Specification:

    The width of Longitudinal Cutting is less than 1.8m or equal to 1.8m.

    The thickness of longitudinal cutting is between 0.8mm and 12mm.

    The width of Open-flat is less than 2m or equal to 2m.

    The thickness of Open-flat is less than 16m or equal to 16m.



    Hot-dip galvanized steel coils are produced by immersing steel in a zinc bath.

     An appropriate galvanizing process requires a pretreatment process during which the steel passes

     through different baths which prepare the surface for zinc coating. In this stage, chemicals are used

     to clean the surface of the steel. After the chemical treatment, the steel coils pass through a bath of

     melted zinc at temperatures around 460 ° C. The resulting uniform coating is finished through a process

     of skin-passing to provide smooth and shiny appearance of the finished product.

    To store for a longer period, the hot-dip galvanized coils can be delivered with a final oil coating,

    according to the customer’s demand. PROFILAND STEEL produces hot-dip galvanized steel coils with

    very good workability at further cold forming and bending processes.



    We are also engaged in the products: Hot rolled steel pipe/tube, Stainless welded steel pipe/tube, ERW steel pipes/tubes, SHS welded steel pipe/tube, RHS welded steel pipe/tube, Galvanized steel pipes/tubes, Round galvanized steel pipe/tube, Square galvanized steel pipe/tube, Rectangular galvanized steel pipe/tube, Pre-galvanized steel pipe/tube, Round pre-galvanized steel pipe/tube, Square pre-galvanized steel pipe/tube, Rectangular pre-galvanized steel pipe/tube, Seamless steel pipes/tubes, Seamless carbon steel pipe/tube, Carbon steel seamless pipe, Stainless seamless steel pipe/tube, Petroleum casing tubes/pipes, API 5L steel pipe/tube, API 5CT steel pipe/tube, Spiral welded steel pipes, Anti-corrosion pipe/tube, 3PE/3LPE/2PE/FBE Anti-corrosion steel pipe, plastic coating and lining anti-corrosion steel pipe, IPN 8710 non -poison lining anti-corrosion steel pipe, Epoxy coal tar pitch coating anti-corrosion steel pipe, Cement mortar lining anti-corrosion steel pipe, Insulation pipe/tube, black jacket foaming layer insulation steel pipe, yellow jacket PU foam insulation steel pipe, PE casting + PU foam layer insulation steel pipe, hot rolled steel in coils/sheets, galvanized steel coil, galvalume steel coil , pre-painted/color coated steel coil, steel strip and steel plate. The application of our products covers oil, natural gas, shipbuilding, chemical industries, environmental protection, boiler making, water/air/steam heating/gas/oil conservancy, power, steel structural products, building, our products are also used in mine air pressure, drainage, drainage gas and slurry transportation etc.


    Tianjin Xuanqusheng International Trading Co., Ltd has established and maintains long term cooperation with numerous famous domestic companies thanks to the management and technical strength of its parent company.Our company now owns 16 production lines, 8 longitudinal shearing machines and 1 cold rolling mill, and develops and exploits internal wall FBE and external wall 3LPE on the steel pipes and stainless steel interlining welding technology, both of them have got the patent of Tianjin . Our company has advanced three production lines of internal wall FBE, external wall heat complex three layers PE (can do the anti-corrosion treatment on the steel pipes, diameter range from 32mm-2820mm, and length from 5m to 18m, install the on-line electrical spark inspection machine, thickness inspection instrument, on-line code spray, inspection data stored on computer, which can keep and track for 5 years).The annual output is 400,000 tons. Our strong advantages in resources have enabled us to supply products in complete range to both domestic and international clients and meet their needs to control the cost to maximize profit.
