Composite Door Engraver Open Source CNC Router Accept 220V Voltage

Composite Door Engraver Open Source CNC Router Accept 220V Voltage

    • Composite Door Engraver Open Source CNC Router Accept 220V Voltage
    • Composite Door Engraver Open Source CNC Router Accept 220V Voltage
  • Composite Door Engraver Open Source CNC Router Accept 220V Voltage

    Product Details:

    Place of Origin: China
    Brand Name: JBT
    Certification: CE/ISO9000
    Model Number: JD3-2513

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiation
    Packaging Details: PE film, wooden box need extra cost
    Delivery Time: 30 working days after receive deposite
    Payment Terms: T/T or L/C
    Supply Ability: 10set/per month
    Contact Now
    Detailed Product Description
    Application: Woodworking Technology: Trimming,shaping,drilling
    Body: Steel Tube Operation System: Taiwan Syntec
    Rail: Taiwan Hiwin30 Working Speed: 15000mm/min
    Electric Component: France Schneider Table Fix: Vacuum Absorbtion
    Name: Open Source Cnc Router

    Composite Door Engraver Open Source CNC Router Accept 220V Voltage



    Equip Parts


    (1) Japan yaskawa servo motor
    (2) Italy air-cooling spindle
    (3) Taiwan ATC rotary carrousel
    (4) Taiwan syntech control system



     Top quality specification

    1). The machine’s body is strong, high-precision, reliable and durable.

    2). Imported high-precision ball screw, which moving smoothly, to ensure the machine’s high precision.

    3). Well-known HSD spindle, strong cutting ability, low noise, to ensure the machine working for long time.

    4). High-performance driven motor to ensure the machine’s high speed and accuracy.

    5). Perfect design and top quality accessories to minimize the machine’s failure rate.

    6). Breakpoint specific memory to keep the carving status when power off, processing time forecast and other functions in case of the accidental power outages.

    7). High speed servo motors and drivers, and two motors for Y axis.



    Main products



    1. Multi spindle cnc router.  mainly for general woodworking industry



    2. ATC cnc router.  mainly for autometic,high precision woodworking process



    3. 4 axis cnc router. mainly for cylinder,chair legs,handle processing



    4. 5 axis cnc router. mainly for wooden mould/pattern sculpture making





    Configuration:



    X axis

    2500mm, Ball screw motion

    Y axis

    1300mm,  Diagonal rack motion

    Z axis

    200mm, Ball screw motion

    Max speed

    35m/min

    Table fix

    VAacuum or clamp

    Rail

    Taiwan Hiwin25

    Spindle

    4.5 kw air cooling

    Spindle speed

    24000r/min

    Motor

    Japan Yaskawa servo motor

    Motor power

    1.3kw

    Operation system

    china

    Process precision

    0.05mm

    Automatic lubrication system

    Yes



    Sample



    Composite Door Engraver Open Source CNC Router Accept 220V Voltage



    Composite Door Engraver Open Source CNC Router Accept 220V Voltage
