Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal

Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal

  • Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal
  • Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal
Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal
Product Details:
Place of Origin: China
Brand Name: YLD
Certification: CE/ SGS
Model Number: YLC-4
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed with EPE, and then with plywood case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or western Union or L/C
Supply Ability: 500 units per month
Contact Now
Detailed Product Description
Item: Water Magnetic Treatment Use: Descaler
Inlet & Outlet Diameter: DN100mm/4 Inch Flow Rate: 80 M3/Hr
Material: SUS 304/316/316L Connection Mode: Flange
Working Temperature: 0~90 ℃ Magnetic Power: 5000 Gauss
High Light:

magnetic water treatment systems

,

magnetic water softeners

Farming Irrigation Magnetic Water Treatment Devices For Bacteria and Algae Removal





Water is the most commonly used media for cooling, be it internal combustion engine, compressors,

furnaces,

 Air conditioners etc. the reason being it absorbs maximum heat per cubic centimeter and does not

 become a

hazard. Oil and other liquids carry much less heat and are fire hazards too. Water, as obtained

naturally, has one major problem i.e. tendency to form scales on the pipes or other areas in which

 it is circulation especially when

hot.



Magnetic Anti Scale Unit

• It requires No chemicals, No salts, No energy, No backwashing

• Easy to Install

• Just connect directly to the main water supply.

• Does Not Affect

• The quality or taste of the water





Operating Principle

Molecules (CaCo3, Potassium, Manganese, etc.) which are in natural suspension in water,

tend to form macro molecules which, if nothing is done, continue to coagulate, causing scale

 to collect in the pipes

with resultant reduction in flow and increased consumption of energy.

Technical Principles

Permanent magnets are installed along the entire length of the appliance, the lines of magnetic

 flux

being captured by a mild iron cylinder (care being taken that the flow-rate is not affected.)





What Is The Result?

When passing through the magnetic field, the macro-molecules are polarized in such a way that their conglomerate structure is deliberately

 disorganized so

 that their original molecular state of natural suspension in the water is re-established. After passing through

 this induced field, they will retain a residual magnetic charge

 for

more than 30 hours (which is substantially longer than the water renewal cycle, which does not

 exceed 12 hours); they cannot therefore recoagulate. In the case of ferruginous water, ferrous

and ferric

welding residues, an anti-corrosion process is established (thus eliminating electrolysis phenomena.)



 Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal 0
Specifications: (The practical dimension could be customized )

Model

                Inlet and outlet

Dimension(mm)

Flow rate

Vertical center

Working medium

weight



mm

inch

diameter*length

m3/h

strong magnetism (mt)

temperature (℃)

Kg

YLC-1

25

1

108×330

4.9

160

0-90

10

YLC-1.5

40

1.5

108×330

12

160

0-90

20

YLC-2

50

2

159×450

19

160

0-90

30

YLC-2.5

65

2.5

159×450

28

160

0-90

40

YLC-3

80

3

159×450

50

160

0-90

45

YLC-4

100

4

219×560

80

160

0-90

50

YLC-5

125

5

219×600

125

160

0-90

60

YLC-6

150

6

273×740

180

160

0-90

70

YLC-8

200

8

325×790

320

160

0-90

90

YLC-10

250

10

377×850

480

160

0-90

110

YLC-12

300

12

426×800

600

160

0-90

130

YLC-14

350

14

478×950

750

160

0-90

160

YLC-16

400

16

530×1000

850

160

0-90

210

YLC-18

450

18

630×1050

950

160

0-90

260

YLC-20

500

20

720×1100

1100

160

0-90

330



Application


Heating/Cooling/Ventilation

prevents limescale in water heating equipment

prevents algae, bacteria and scale in swimming pools and cooling towers



Cooling Towers

prevents algae, bacteria and scale in swimming pools and cooling towers



Steam Boiler/Steam systems

prevents limescale in high pressure steam boilers



Hazardous sites Anti scale formation systems

designed specifically for industry producing in hazardous environments



Agriculture

protection systems for poultry, diary, irrigation, greenhouse, fish farms, ponds, fountains etc.

maintains your irrigation & water systems by prevening blockages caused by scale build up

Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal 1



Working principle
 It is based on a process which treats water without altering its mineral composition. Water

flows through a magnetic coil from highly efficient permanent magnets. In this cell the water

 crosses a magnetic field perpendicular to the lines of induction. This contact polarizes the

molecules contained in the water, thereby disrupting the normal crystallization process of

mineral salts such as calcium and magnesium. Once these salts have been physically modified

in this way, they lose their ability to attach themselves to the lining of pipes and tanks.

 Farming Irrigation Magnetic Water Treatment Devices Bacteria , Algae Removal 2





FAQ:

01. What is the capacity(m3/hour)you required for this equipment?
or you could confirm diameter of the water pipe.
02. What is the material for this descaling equipment?
Ordinary carbon steel is Okay? stainless steel(SS304/SS316)?
Which means,what is the source of raw water to be treated?
03. What is the magnet power for it?
ordinary 5000 gauss?or higher?
