Product Details:
Place of Origin: Guangdong China
Brand Name: Caterly
Certification: CE,ISO9001,SGS,CQC
Model Number: F-150W
Payment & Shipping Terms:
Minimum Order Quantity: 10 Sets
Price: USD 280/Set to USD345/Set
Packaging Details: Bubble bag and cardboard boxes and wooden case
Delivery Time: 3-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 2000Set per month
Contact Now
Detailed Product Description
Product Material: Aluminum Alloy Brand Name: Caterly
Trail Size: 4200*150*110 (mm) Weight:: 9.28KG
Door Weight: 150*1 / 150*2 Model: F-150W
Color: Silver
High Light:

electric sliding doors

,

automated sliding door

power plant with imported technology  Brushless DC motor Auto Sliding Door Operator



Advantage:



Automatic sliding glass door operator

Stable, Strong, Safe, Silence

CE & ISO9001

2 YEARS Warranty

OEM and ODM are available

Technical Data:

Power suppler: 220V50/60HZ

Motor: 24V brushless motor, 100W

Opening speed: Max 750mm/s (Adjustable)

Closing speed: Max 600mm/s (Adjustable)

Opening pause time: 0~15s (Adjustable)

Max leaf weight: 150kgs/leaf (single opening), 150kgs/leaf (double opening)

Battery charger: able to open and close 200 times during a power cut (optional)

Operating temperature: -20°C~55°C

Automatic locked

Track length: 2.1 to 4.2m

With 1 million times of tests passed

CE standards

Warranty: 24 months

With intelligent design, easy to install and adjustable



Packaging & Delivery

Packaging Details: automatic door commercial sliding door operator packing: 505*305*150mm for kit 4250*150*110 mm for track
Delivery Detail: 7 workdays for order of 300 sets



Production Information

 Type:               F-150W

 Component : 1. Motor  2.Micro-Controller  3. Rear wheel  4. Belt

                         5. Hanger sets  6. Track 7. Cover 8. Belt  holder 9.Sensor   10. End Stop

Track Length :  2100mm , 3000mm , 4200mm , 6000mm



Optional Accessories
