DC Gear motor for Automatic Sliding Door 24VDC Black Coating , Gear Ratio 1:15

DC Gear motor for Automatic Sliding Door 24VDC Black Coating , Gear Ratio 1:15

  • DC Gear motor for Automatic Sliding Door 24VDC Black Coating , Gear Ratio 1:15
DC Gear motor for Automatic Sliding Door 24VDC Black Coating , Gear Ratio 1:15
Product Details:
Place of Origin: Jiangxi, China
Brand Name: Ccoem
Certification: CE/CCC
Model Number: YX-4008-E3
Payment & Shipping Terms:
Minimum Order Quantity: 300pcs
Price: To be discussed
Packaging Details: Standard export carton or pallet,10pcs/carton, 25ctns/pallet, Net weight 1.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Commutation: Brush Construction: Permanent Magnet
Dia: 36mm Function: Driving
Torque: 3-20Kg.cm Type: Gear Motor
Usage: Home Appliance
High Light:

planetary geared motor

,

small gear motors



DC Gear motor for Automatic Sliding Door 24VDC Black Coating , Gear Ratio 1:15



Quick Detail:



Brushless Automatic Sliding Door Motor, Long Lifetime and Noise-free 24VDC 65W,4200RPM





Description:



Permanent Magnet Brushless DC motor, worm gear box type

Gear material: Strengthened Plastic or Bronze

Aluminum Diecasting Gearbox

Motor housing: D60.5mm, Black coating

Rolled Steel Housing Construction

Encoder available

Various Output Shaft extension

Metal or Plastic pulley available





Specifications:



  • HS code: 8501310000
  • Voltage: 24VDC
  • Power: 65W
  •  speed: 4200rpm
  • Gear Ratio: 1:15
  • Rotate direction: CW and CCW
  • Protection class: IP 44
  • Life time:3million cycles,10years





Applications:



Widely used in interior automatic sliding door system





Competitive Advantage:



CE certified:

  • EC declaration of LVD conformity: low voltage, 2006/95/EC directive
  • Certificate number: CLZJ1205291170
  • EC declaration of EMC conformity: 2004/108/EC
  • Certificate number: CEZJ1205291171

CE, CCC compliant, QC under ISO9001:2008

Working temperature range -25C to + 60C

10years lifetime, without need for replacement

Silent working, Low noise, Easy installment, Reliable performance
