Electric Sliding Gate Motor Automatic Warm - Up With Mode Number 4

Electric Sliding Gate Motor Automatic Warm - Up With Mode Number 4

  • Electric Sliding Gate Motor Automatic Warm - Up With Mode Number 4
Electric Sliding Gate Motor Automatic Warm - Up With Mode Number 4
Product Details:
Place of Origin: China
Brand Name: WONSUN
Certification: CE, ISO, SGS
Model Number: WSTP120
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: negotiation
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Delivery Time: 3-7 working days after received your payment
Payment Terms: T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc.,
Supply Ability: 1000 Sets/Month
Contact Now
Detailed Product Description
Power Supply Range: AC220V/110V±10% 50/60Hz Max Loading Weight: 1500kg
Open(close) Speed: V=12m/min Rated Power: 200w
Working Temperature Of Motor: -25 To +55 Celsius Degree Output Gear Module: M=4
High Light:

Electric Sliding Gate Motor

,

Slide Gate Motor

Electric Sliding Gate Motor Automatic Warm - Up With Mode Number 4





Quick Detail:



Name: Sliding gate motor

Power supply range: AC220V/110V±10%  50/60Hz

Net weight: 8.5kg

Working temperature of motor: -25 to +55 Celsius degree

Working humidity: ≤85%

Rated power: 200w

Output gear module: M=4

Output gear number: Z=16

Open(close) speed: v=12m/min





Each kit includes:

  • 1 x motor
  • 2 x remote controllers
  • 1 x control panel
  • 1 x base plate
  • 2 x magnets
  • 1 x user's manual

Functions of sliding gate operators:



1) Integrated mechanical and electrical, all functions on one controller

2) Radio controller or lines to control open, close and stop functions

3) Magnetic limit switch, the door stops when it moves to the limit

4) Accurate limit braking

5) Electronic soft-start

6) Dialing switches to adjust the motor rotation in both directions

7) Open and close limits have a self-locking function

8) Intelligent operation - if an obstacle is detected when the door is closing, it will reverse to open, then after 10seconds it attempts to close automatically unless you press the stop keystroke

9) Movement indication - the indicator lights up when the door is moving

10) Optional line control or remote control



Sliding gate motor description:

  • Single phase
  • Speed up to 600mm per second
  • Manual override release clutch
  • Basic features means easy to set up
  • Soft starting and stopping function
  • All electric enclosed in a protective enclosure
  • 100% duty cycle

Others information of sliding gate opener:

  • Guarantee time: 1 year
  • Delivery deadline: 8 days delivery after receive your payment
  • Package: 1 set in a standard carton packing
  • Minimum order

Packing list

Name

Quantity

Unit

Remark

Sliding gate operator

1

set

Necessary

Remote control

2

pcs

Necessary

Internal hexangular bolt

4

pcs

M8*40

Internal hexangular bolt

4

pcs

M6*16

Left limit iron

1

pcs

Necessary

Right limit iron

1

pcs

Necessary

Base board

1

pcs

Necessary

Release key

2

pcs

Necessary

Manual

1

pcs

Necessary

Infrared photocell

1

set

Optional

Radio emitter

1

set

Optional
