Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door

Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door

Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door

Product Details:

Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4001

Payment & Shipping Terms:

Minimum Order Quantity: 300PCS
Price: Negotiation
Packaging Details: Standard export carton or pallet,10pcs/carton, weight 2.0kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Motor Type: Brush Voltage& Power: 24VDC, 100W
Construction: Permanent Magnet Rotation Direction: Reversible
Application: Automatic Sliding Door Encoder Available: 2 Signals, 100pulse, Honeywell Brand



Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door ​



Description:



A brushed DC motor is an internally commutated electric motor designed to be run from a direct current power source. Brushed motors were the first commercially important application of electric power to driving mechanical loads, and DC distribution systems were used for more than 100 years to operate motors in commercial and industrial buildings.





Applications:



Brushed motors continue to be used for electrical propulsion, cranes, paper machines and steel rolling mills. Since the brushes wear down and require replacement, brushless DC motors using power electronic devices have displaced brushed motors from many applications



Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door



Specifications:



Brush DC Door Motor Parameters:

Code

4001-1

Type

Brush

Voltage

24VDC

Power

100W

No load Speed

220rpm

No load Current

1.0A

On load Speed

180rpm

On load Current

4.5A

Stall torque

17Nm

Protection class

IP44

Weight

2.0kg

Encoder Honeywell

2signals,100pulse







Brush DC Door Motor Outline drawings:



 Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding DoorEncoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door





Automatic sliding Door Application Examples:





Encoder 2 Signals 100W 24V DC Brush Gear Motor for Automatic Sliding Door





Competitive Advantage:



The DC Brush Motor is one of the earliest of all electrical motor designs. It is usually the motor of choice for the majority of torque control and variable speed applications. The following discusses the advantages and disadvantages of using a Brush DC Motor in machinery and automated processes.
