24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor

24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor

  • 24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor
24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor
Product Details:
Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4009
Payment & Shipping Terms:
Minimum Order Quantity: 300PCS
Price: Consultation get the latest price
Packaging Details: Standard export carton or pallet,10pcs/carton, weight 2.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
High Light:

sliding door motors

,

small brushless motor

24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor





Quick Detail:



Code: 4009   Type: Brushless   Operation Voltage: 24VDC   Power: 75W

Rotate Direction: CW &CCW    Application: Automatic door   Door Open style: Sliding

Opening type: With Remote Control   Function able: Automatic operation/hold-open/closed/half-open

Security: Automatic stop/reverse during opening or closing

Door Weight Bearable: 300kg /2 Leaves     Door Width: 650~1600mm

Environment temperature: -20 ~ +50ºC      Lifetime: 3million cycles, 10years





Description:



Brushless motor is drive device for automatic sliding doors, with silent operation, has big torque, long service life and high efficiency. It adopts European technology to integrate motor with gear box, which offers strong driving and reliable operation and increased power output, it can adapt to a large doors. Helical gear transmission in the gear box ensures the stable and reliable operation, even used for heavy door, the whole system operates easily.



The control device of sliding automatic door contains basic function and extensional function, automatic operation/hold-open/closed/half-open to meet customer needs. Opening/closing speed setting and adjustment is accurately controlled by microcomputer controller.




Applications:



Square Brushless DC Motor can be used for any kinds of automatic doors: Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, Hospital Door

Which are widely used in Hotel, Hospital, Shopping Mall, Bank, Commercial office building, etc.





Specifications:



Automatic Sliding Door Motor Specs:

Code

4009

Type

Brushless

Rated Voltage

24VDC

Rated Power

75W

No-load speed

185rpm

On-Load speed

150rpm

Noise level

≤50dB

Protection class

IP54

Weight

2.5kg

Gear Ratio

1:12

Lifetime

3million cycles,10years

Application

Automatic door





 Automatic sliding door Working orbit:



24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor 0





Outline drawings of Automatic Sliding Door Motor:



24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor 1





Automatic sliding door Application Examples:



24V Automatic Sliding Door Motor with Silent Working / Square Brushless DC Motor 2
