Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type

Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type

  • Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type
Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type
Product Details:
Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4004-2
Payment & Shipping Terms:
Minimum Order Quantity: 300PCS
Price: Negotiation
Packaging Details: Standard,10pcs/carton, weight 2.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
High Light:

sliding door motors

,

brushless gear motor



Power Door Motor - Sliding Automatic Door Heavy Duty Brushless 24VDC Gear Motor Round Type





Quick Detail:



Motor Type: Brushless, 24VDC, 75W

Door Type: Sliding doors

Brushless Motor/Dimension: 280*100*90mm

Safety Detection: Automatic Stop /Reverse during Opening or Closing

Door Weight: 1X300kg/2X150kg   Door Width: 650~1600mm





Description:



1) Input power supply AC110V-240V;
2) DC24V brushless motor

3) Door Weight 300kg/single leaf, 2X150kg/ Double leaves

4) Door Width: 650~1600mm

5) Maximum Noise below 50dB

6) Railing Type: High Strength Aluminum Alloy Rally

7) Fixed Pulley Hanging Wheel Sets/Convenient Level Adjustment/Automatic Alignment/Easy Installation

8) Working Temperature-25~ c+55 c




Applications:



This Round type Brushless DC Motor can be used for frame or frameless Sliding Glass Door Operators.





Specifications:



Brushless dc motor:



Type

Brushless

Voltage

24VDC

Power

75W

No-load speed

150rpm

On-load speed

120rpm

Noise level

≤50dB

Protection class

IP44

Gear Ratio

1:15

Weight

2.5kg

Lifetime

3million cycles,10years

Application

Sliding Glass door





Competitive Advantage:



1. LOW NOISE than brushed motor, because of its precise manufacturing technology and direct driving design.



2. Brushless motors have LONG LIFE than brushed motors (more than 3,000,000 cycles), with 10years warranty.



3. Small size and Excellent Design, high-strength wear-resistant gears and high processing makes it more stable, quiet, longer life, higher efficiency, larger torque.



4. Leading technologies, multi- functions, dependable performance while being cost efficient.



5. Widely used for Automatic Doors: including Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, Hospital Door, be installed in the hotels, airports, office buildings, shopping malls, hospitals etc.



Motor Outline drawings:



Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type 0





 Automatic sliding Glass door Operator:



Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type 1





 Automatic sliding Glass door:



Power Door Automatic Sliding Door Motor Heavy Duty Brushless 24VDC Gear Motor Round Type 2
