Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder

Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder

Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder

Product Details:

Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4001

Payment & Shipping Terms:

Minimum Order Quantity: 500PCS
Price: Negotiation
Packaging Details: Standard pack,10pcs/carton, weight 2.0kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Construction: Permanent Magnet Rotation Direction: Reversible
Motor Type: Brush, 24VDC, 100W Application: Automatic Sliding Door
Door Configuration: Single Door, Double-door Encoder Available: 2 Signals, 100pulse, Honeywell Brand



Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder​

 ​



Description:



The advanced brush dc motor supported by intelligent Honeywell software can self-learn the stroke. The brush motor and the worm-reduction gear are integrated together, with advantageous features such as higher efficiency, larger torque and longer life span. The motor noise is extremely low because of its precise manufacturing technology and direct driving design. The motor can lock automatically if there is no triggering signal. The powerful closing force keeps the door shut fast.





Specifications:



100W 24VDC Automatic sliding Door Motor specs



Type

Brush

Voltage

24VDC

Power

100W

No load Speed

220rpm

No load Current

1.0A

On load Speed

180rpm

On load Current

4.5A

Stall torque

17Nm

Protection class

IP44

Weight

2.0kg

Encoder Honeywell

2signals,100pulse





Outline drawings of 100W 24VDC Automatic Sliding Door Motor:



Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder



Applications:



This kind of brush gear dc motors are used for Automatic sliding door operators, interior door operators, telescopic door operators, automatic swing door operators, emergency evacuation automatic doors and curved doors, which are widely used in hotels, banks, airports, commercial buildings, hospitals and factories.



Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder

Golden Color Heavy Load Automatic Sliding Door Motor / DC Gear Motor with Encoder





Competitive Advantage:



1) Silent operation, suitable for continuous service;
2) Micro-computer controller, self setup and adjustment;
3) Automatic stop when meet obstacles during opening, automatic reverse when meet obstacles during closing;
4) Adjustable door opening speed and distance;
5) Automatic closing function after opening, auto closing time adjustable;
6) Soft start and soft closing;
7) Full open or half open optional;
8) Easy open the door leaf by hands during power off;
9) High density aluminum track, special configuration design keep in shape always;
10) Smooth operation of the track, good for continuous service, quiet operation.
