High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse

High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse

High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse

Product Details:

Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4001-2

Payment & Shipping Terms:

Minimum Order Quantity: 500PCS
Price: Negotiation
Packaging Details: Standard pack,10pcs/carton, weight 2.0kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description



High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse​





Quick Detail:



Motor Type: Brush, 24VDC, 100W

Construction: Permanent Magnet

Rotation Direction: Reversible

Application: Automatic sliding door

Door configuration: Single door ,  Double-door

Encoder available: 2 signals, 100pulse, Honeywell brand





Description:



The advanced brush dc motor supported by intelligent Honeywell software can self-learn the stroke. The brush motor and the worm-reduction gear are integrated together, with advantageous features such as higher efficiency, larger torque and longer life span. The motor noise is extremely low because of its precise manufacturing technology and direct driving design. The motor can lock automatically if there is no triggering signal. The powerful closing force keeps the door shut fast.





Applications:



This kind of brush gear dc motors are used for Automatic sliding door operators, interior door operators, telescopic door operators, automatic swing door operators, emergency evacuation automatic doors and curved doors, which are widely used in hotels, banks, airports, commercial buildings, hospitals and factories.





Specifications:

Automatic door motor specs:



Type

Brush

Voltage

24VDC

Power

100W

No load Speed

220rpm

No load Current

1.0A

On load Speed

180rpm

On load Current

4.5A

Stall torque

17Nm

Protection class

IP44

Weight

2.0kg

Application

Automatic glass door





Automatic door motor test:



High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse





State

Voltage

Current

Pin

Torque

Speed

Pout

Eff

V

A

W

N.m

rpm

W

%

Speed_max

24.04

0.671

16.15

0.29

223.9

6.79

42.0

Eff_max

24.04

1.778

42.77

1.29

210.0

28.36

66.3

Pout_max

24.03

12.00

288.6

8.62

115.0

103.8

35.9

Torque_max

24.03

22.33

536.6

16.67

0.0

0.00

0.0

End

24.03

22.33

536.6

16.67

0.0

0.00

0.0





Automatic door Operator:



High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse



Automatic door Motor application:



High Torque Automatic Door Motor with Encoder 2 Signals , 100Pulse





Competitive Advantage:



1)  Silent operation, suitable for continuous service;
2)  Micro-computer controller, self setup and adjustment;
3)  Automatic stop when meet obstacles during opening, automatic reverse when meet obstacles during closing;
4)  Adjustable door opening speed and distance;
5)  Automatic closing function after opening, auto closing time adjustable;
6)  Soft start and soft closing;
7)  Full open or half open optional;
8)  Easy open the door leaf by hands during power off;
9)  High density aluminum track, special configuration design keep in shape always;
10)  Smooth operation of the track, good for continuous service, quiet operation.
