Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound

Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound

  • Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound
Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound
Product Details:
Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4009
Payment & Shipping Terms:
Minimum Order Quantity: 300PCS
Price: Negotiation
Packaging Details: Standard,10pcs/carton, weight 2.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Type: Brushless Voltage Power: 24VDC
Application: Automatic Door Open Style: Sliding
Opening Type: With Remote Control Function Able: Automatic Operation/hold-open/closed/half-open
Door Weight Bearable: 300kg /2 Leaves Door Width: 650~1600mm
Environment Temperature: -20 ~ +50ºC Lifetime: 3million Cycles, 10years
High Light:

power sliding door motor

,

motor for sliding door

Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound



Description:



Brushless motor is drive device for automatic sliding doors, with silent operation, has big torque, long service life and high efficiency. It adopts European technology to integrate motor with gear box, which offers strong driving and reliable operation and increased power output, it can adapt to a large doors. Helical gear transmission in the gear box ensures the stable and reliable operation, even used for heavy door, the whole system operates easily.





Applications:



Square Brushless DC Motor can be used for any kinds of automatic doors: Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, and Hospital Door

Which are widely used in Hotel, Hospital, Shopping Mall, Bank, Commercial office building, etc.





Specifications:

Brushless Motor:



Type

Brushless

Rated Voltage

24VDC

Rated Power

75W

No-load speed

185rpm

On-Load speed

150rpm

Noise level

≤50dB

Protection class

IP54

Weight

2.5kg

Gear Ratio

1:12

Lifetime

3million cycles,10years

Application

Automatic door







Physical Dimensions:



Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound 0







 Automatic sliding Glass Door Operator:



Shopping Mall Automatic Door Square 24V Brushless Motor with High Power Small Sound 1





Competitive Advantage:



1. LOW NOISE and LONG LIFE than brushed motor, because of its precise manufacturing technology and direct driving design.Brushless motors can work more than 3,000,000 cycles, with 10years warranty. powerful closing force keeps the door shut fast. Internal circuit protection device safe, even if the frequent opening and closing, also can achieve long-term trouble free operation



2. Small size and Reasonable Design, high-strength wear-resistant gears and high processing makes it more stable, quiet, longer life, higher efficiency, larger torque. Leading technologies, multi- functions, dependable performance while being cost efficient.



3. Convenience&Safety: Adjustable opening /closing speed , distance, Auto close delay time etc.

During power failure, doors can be opened manually.Automatic stop when meet obstales during opening,automatic reverse when meet obstales during closing, Automatic lock if there is no triggering signal.



4. Easy Installation: Good modular design offers very easy installation. Only need to fit all components into the guide rail and connect each part well, it can work after activating the power supply.


5. Wide Application: used for Automatic Doors: including Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, Hospital Door, be installed in the hotels, airports, office buildings, shopping malls, hospitals etc.
