3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature

3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature

    • 3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature
    • 3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature
    • 3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature
    • 3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature
  • 3.5inch TFT LCD Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature

    Product Details:

    Place of Origin: China
    Brand Name: SPEEDATA
    Certification: IP65,GB/T 18220-2000
    Model Number: MT35CBW-R3-D6T
    C-MOS imager: 5M AF
    External Interface: USB HOST/RS232/SPI/IIC
    Protection class: IP65
    Drop resistance level: 1.5m
    Weight: >400g with battery (according config)
    Dimension: 182*82*36mm
    Contact Now
    Detailed Product Description





    3.5inch Humidity Sensor Portable Data Collection Terminal for Greenhouse Temperature





    Quick Detail:





     Core Board





    WM6.1/6.5 OS option 1 Marvell PXA310(624MHz)+qualcomm (GSM band 900/1800/1900MHz, GPRS,  EDGE/WCDMA 2100MHz HSDPA 3.6Mbps)
    Android 2.3 OS yes Marvell PXA910(806MHz)+qualcomm
    (GSM Quad-band 850 /900 /1800 /1900 MHz, GPRS, EDGE
    WCDMA 3G 900/1710/2100MHz HSDPA 3.6Mbps
    Memory Flash ROM 512MB
    RAM 256MB DDR
    Extend Slot Micro SD 16G (SDHC)





    Data sheet





    Display  3.5inch TFT LCD (Transflective screen VGA )
    touch screen 4-wire resistive
    Form Factor Bar type classical Pocket PC,Industrial appearance
    GPS Qualcomm chipset (WM OS)
    UBLOX module (Android OS )
    Bluetooth

    Bluetooth SIG version 2.0 compliant; Supported profiles: headset,

    hands-free, object push, serial port, dial-up network

    WiFi WiFi (802.11 b/g/n)
    Fingerprint reader(yes) SM-621B
    Thermal Printer  (Optional) Direct thermal line printing
    Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
    PSAM (optional) PSAM ISO 7816 class A,B
    RFID Reader option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
    option 2 LF RFID(125KHz)
    option 3 HF RFID(13.56MHz ISO 14443A/B)
    option 4 HF RFID(13.56MHz  ISO 1443A/B    ISO 15693)
    yes

    UHF RFID 860-960MHZ  ISO18000-6C (EPC Gen2)  /

    ISO18000-6A,B compatibility in direct mode

    barcode scanner option 1 NEWLAND:EM1300(1D barcode reader)
    option 2 NEWLAND:EM3000(1D/2D barcode reader)
    option 3 symbol:SE955(1D laser barcode reader)
    option 4 HoneyWell:N4313 (1D laser barcode reader)
    option 5 Honeywell:5100(1D/2D barcode reader)
    option 6 Symbol: se4500(1D&2D barcode reader)



    Competitive Advantages :


    1. We have our own manufacture in Beijing ;

    2. Scientific management, advanced production equipment;

    3. Own r&d team and technical personnel;

    4. Excellent after-sales service and technical support;
