Name: DJM-500-3P Automatic sliding door motor
Brand: FUCHANG
SKU: DJM-500-3P
Price: 1 USD
Availability: InStock
Rating: 4.9 (129 reviews)

Home Products Automatic Sliding Door Motor

DJM-500-3P Automatic sliding door motor

Product Details:

Place of Origin:	China
Brand Name:	FUCHANG
Certification:	CCC, CE
Model Number:	DJM-500-3P

Payment & Shipping Terms:

Minimum Order Quantity:	100PCS, SAMPLE AVAILABLE
Price:	USD 1~249 / Set
Packaging Details:	CARTONS
Delivery Time:	ACCORDING TO THE QUANTITY OF ORDER
Payment Terms:	L/C,T/T
Supply Ability:	10000 SETS PER MONTH

Contact Now

Detailed Product Description

High Light:

automatic sliding door motor

garage door motor

electric shutter motor

OEM manufacturer for Automatic sliding door motor

Feature

Left or right installation is ok
design controller with different funtions according to customers request.
300kgs/500kgs could add reserve power function
overheat protection:if the motor temperature is over 110 degreed centigrade, the motor stops working automatically, works again if temperature return below 70 degreed centigrade
It can be operated by electricity and manual
Durable compact design great elevating power with low noise
Could match infrared sensor or alarm system(optional)
Four relays inside the motor,four micro-active switch inside the limit system
Features:

Automatic sliding door motorMain Specifications

Model	Motor Power(W)	Max.lifting force(KG)	Max.hosting height(M)	Max.output Torque(N.W)	Rated Current(A)	Large Sprocket Reel Speed(R/MIN)	Chain No.
Power Supply(V/HZ): 220/50
DJM-300-1P	250	300	6	168	3.3	4.8	08B
DJM-400-1P	250	400	6	225	3.3	4.8	08B
DJM-500-1P	370	500	6	343	3.9	4.8	10A
DJM-600-1P	370	600	6	412	3.9	4.8	10A
DJM-800-1P	400	800	9	647	4.5	3.94	10A
DJM-1000-1P	400	1000	9	809	4.5	3.75	12A
Power Supply(V/HZ): 380/50
DJM-600-3P	250	600	6	412	1.2	4	10A
DJM-800-3P	300	800	9	647	2.0	3.94	10A
DJM-1000-3P	400	1000	9	1102	2.3	3.74	12A
DJM-1300-3P	600	1300	9	1372	3.0	4.4	12A
DJM-1500-3P	600	1500	9	1610	3.2	5.2	16A
