| Place of Origin: | Guangdong China |
| Brand Name: | Caterly |
| Certification: | CE,ISO9001,SGS,CQC |
| Model Number: | SW200 |
| Minimum Order Quantity: | 10 Sets |
|---|---|
| Price: | USD 225/Set to USD500/Set |
| Packaging Details: | Bubble bag and cardboard boxes and wooden case |
| Delivery Time: | 3-7 work days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 2000Set per month |
| Door Material: | Aluminum Alloy,Glass | Color: | As You Need |
|---|---|---|---|
| Handle: | Wood Or Stainless Steel | Thickness Range: | 3mm-19mm |
| Type: | Automatic Swing Door,Normal Doors, | ||
| High Light: | Auto Swing Door Opener,electric Swing Door Opener |
||
| Packaging Detail: | bubble,carton,cases,wood, |
| Delivery Detail: | within 3 days after receiving your payment |
Automatic swing door mechanisms
1.13 year experience
2. Remote control door
3. 2 years warranty
4. Certification:ISO,CE
Automatic glass swing door
Model |
|
|
| Concealed SD2008 |
Swing application |
|
|
| Two-way open |
Door width |
| 1000mm | ||
Door weight |
|
|
| 200kgs |
Opening speed | 3-8 seconds (adjustable) | |||
Closing speed | 3-8 seconds (adjustable) | |||
Time to open door | 0-120seconds (adjustable) | |||
Open angle | 70-110 degrees | |||
Closing buffer function | Adjustable | |||
Input power static/max | 5W/40W | |||
Buffer speed of opening | Adjustable | |||
Buffer speed of closing | Adjustable | |||
Buffer distance of opening | Adjustable | |||
Buffer distance of closing | Adjustable | |||
Braking force of opening | Adjustable | |||
Braking force of closing | Adjustable | |||
Locked power | Adjustable | |||
Power supply | AC220V to 230V,DC12V | |||
1. Technology
Adpot german high tech, passed CE and ISO 9001-2000.Using brushless DC Motor, 2 years warranty.
2. Advanced motor
Advanced brushless motor and worm wheel reducer are integrated,with lower consumption,energy saving, high efficiency, great torque and long life.with low noise, easy installation.
3. Working procedures
Opening signal-control unlock - open - brake to stop door -keep the door open - self closing - buffer- locked.
4. Controller
The door can be opened or closed by remote control, password swipe card reader,microwave sensor.body sensor, switch button.Intelligent control system with variable adjustable parameters.
5. Safety
Automatic overload protection.Intelligent encountered obstacles protection, Intelligent over-temperature protection,Electric lock control function.The magnetic lock can be installed, make more secure.Safety beam protects the guest from bumping the door, safety and reliable.
6. Adjustable
All models can be adjusted parameters by ajustable controller.
