Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor

Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor

  • Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor
Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor
Product Details:
Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4004-1
Payment & Shipping Terms:
Minimum Order Quantity: 300PCS
Price: Negotiation
Packaging Details: Standard,10pcs/carton, weight 2.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Motor Type: Brushless,24VDC, 100W Door Type: Sliding Doors
Brushless Motor/Dimension: 280*100*90mm Safety Detection: Automatic Stop /Reverse During Opening Or Closing
Door Weight: 1X300kg/ 2X150kg Door Width: 650~1600mm
High Light:

brushless gear motor

,

small brushless motor



Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor​





Description:



1) DC24V brushless motor

2) Input power supply AC110V-240V;
3) Door Weight 300kg/single leaf, 2X150kg/ Double leaves

4) Door Width: 650~1600mm

5) Maximum Noise below 50dB

6) Railing Type: High Strength Aluminum Alloy Rally

7) Fixed Pulley Hanging Wheel Sets/Convenient Level Adjustment/Automatic Alignment/Easy Installation

8) Working Temperature-25~ c+55 c




Specifications:



Type

Brushless

Voltage

24VDC

Power

100W

No-load speed

150rpm

On-load speed

120rpm

Noise level

≤50dB

Protection class

IP44

Gear Ratio

1:15

Weight

2.5kg

Lifetime

3million cycles,10years

Application

Automatic door







Applications:



This round motor type Brushless DC Motor can be used on any kinds of Automatic doors: Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, and Hospital Door etc. Which are widely used in Hotel, Hospital, Shopping Mall, Bank, Commercial office building and etc.



Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor 0



Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor 1







Competitive Advantage:



1. LOW NOISE than brushed motor, because of its precise manufacturing technology and direct driving design.



2. Brushless motors have LONG LIFE than brushed motors (more than 3,000,000 cycles), with 10years warranty.



3. Small size and Excellent Design, high-strength wear-resistant gears and high processing makes it more stable, quiet, longer life, higher efficiency, larger torque.



4. Leading technologies, multi- functions, dependable performance while being cost efficient.



5. Widely used for Automatic Doors: including Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, Hospital Door, be installed in the hotels, airports, office buildings, shopping malls, hospitals etc.





Brushless DC Motor Outline drawings:





Round Brushless DC Motor Silent Work For Heavy Duty Sliding Door operator , 24v brushless motor 2
