Hot - Dip Galvanizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine TW-CBT300

Hot - Dip Galvanizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine TW-CBT300

  Main Specifications Of Cable Tray Roll Forming Machine

• Material: Q235 cold rolled strip or Hot-dip Galvanizing stee strip
• Material Thickness:2.0mm,
• Material Width: 400mm
• Rolling Product Length: 0 limited, 0-any mm
• Rolled Product Straightness Error: 1-1.5mm/1500mm
• Rolling Product Angle Error: ≤±1.5/1000mm
• Motors Explosion-proof Rating: ExdllCT4
• Motor Protection: IP55
• Total Installed Capacity Power: about 31.4 KW
• Forming Station of Cable Tray Roll Forming Machine: 16 Steps
• Speed of Line: 0-10m/min.
• Weight of machine: about 11.5 Ton

  Cable Tray Profile Drawings

  Working Flow

Auoto Decoiler – Tranporting & 9 Rollers Leveling – Servo Feeding -- 100 Ton Punching machine -- Oriented – Transportation – 8 Holes Punching -- Main Forming -- Cutting -- Run out table

  Applications

Cable tray, cable ladder, cable profile, tray profile

   Our Advantages

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

  Machine Pictures

  Factory Pictures

  Certificate
